The secret to splinter-free cuts is full material support at the cutting point. Trion splinter guards are designed to be cut by the blade for perfect zero-clearance between the blade and the splinterguard. The resultant cut is clean through the entire piece with little or no finishing required. The D-handle PSB 300 features a finger tip trigger and smaller profile grip. The PSB 300 has all the qualities of the PS 300, with the addition of a comfortable D-handle for easy one-handed use.
Carbide tipped guidance jaws on Festool jigsaws ensure your blade stays perpendicular to the jigsaw’s shoe at all times, guaranteeing a perfectly perpendicular cut, no matter the style of cut. Additional features such as variable stroke settings for smooth to aggressive cuts, removeable plug it power cord, bevel base and FastFix blade change make this jigsaw best in class.
Advantages
- Carbide guidance system keeps the blade perpendicular to the shoe for improved cut results, even in thick stock.
- Zero clearance splinterguard are solid one-piece inserts that are cut with the blade mounted in the machine for a clean, splinter-free cut.
- Dust extraction channels integrated in the base plate coupled with a clear chip deflector a rear dust extraction port provide for cleaner work area.
- MMC electronics provide soft start to reduce start up jolts, variable speed to match the speed to the material, and constant speed under load.
Technical Data
| Bevel Adjustment | 0º - 45º |
| Cutting Depth, Non-ferrous Metals | 3/4" (20 mm) |
| Cutting Depth, Steel Soft | 3/8" (10 mm) |
| Cutting Depth, Wood | 4 3/4" (120 mm) |
| Power Consumption | 720 watts / 6 amps 120 v AC |
| Stroke Adjustment | Four Stages |
| Stroke Rate (1") | 1,000 - 2,900 spm |
| Weight | 5.29 lbs. (2.4 kg.) |
